SENKO hydrogen single gas detector
Personal Monitor Oxygen (O2) - Image 2

Personal Monitor Oxygen (O2)

SENKO SGTP

£104.00 excl. tax | £124.80 incl. tax

The SENKO SGT-P O2 is a portable single gas detector designed to detect Oxygen deficiency in ambient environments. The SGT-P benefits from having a replaceable gas sensor and battery. Users are able to switch the SGT-P on and off when it is needed, extending single battery life operation. The SGT-P continuously monitors ambient air Oxygen concentration and in the event that depletion or enrichment levels exceeds alarm set points the device alerts the user to potentially unsafe conditions. Outputs include visual, vibration, and audible alarms. The alarm set points (Low and High), calibration range and display configuration can be changed via the SENKO-IR Link. (Optional)

somdn_product_page
SKU: NPL-SP-SGTP-O2 Categories: ,

Description

The SENKO SGT-P O2 is a portable single gas detector designed to detect Oxygen deficiency in ambient environments. The SGT-P benefits from having a replaceable gas sensor and battery. Users are able to switch the SGT-P on and off when it is needed, extending single battery life operation. The SGT-P continuously monitors ambient air Oxygen concentration and in the event that depletion or enrichment levels exceeds alarm set points the device alerts the user to potentially unsafe conditions. Outputs include visual, vibration, and audible alarms. The alarm set points (Low and High), calibration range and display configuration can be changed via the SENKO-IR Link. (Optional)

Measurements

Sensor Type Electrochemical
Metrics Gas        Measuring Range      Low Alarm                     High Alarm
O2        0~30% Vol                     User Selectable          User Selectable
Default 19%                  Default 23%

Applicable Standards

Ex ia IIC T4 Ga/ IP67 (Korea Ex, IECEx, ATEX, CSA & UL, INMETRO

Applications

An Oxygen Concentration Personal Monitor is critical in workplaces or scenarios where oxygen levels might drop below safe thresholds (typically below 19.5% in the air) or rise to dangerous levels (above 23.5%).
Confined Spaces
Food Processing
Welding
Mining & Fabrication
Petrochemical plants
Waste water treatment
Automotive
Pharmaceutical manufacturing
O2 monitors ensure worker safety by continuously measuring oxygen levels in the environment to avoid serious health risks, including unconsciousness, suffocation, or fire hazards.

Specifications

Measuring Type Diffusion Type
Dimension 54 (W) x 91 (H) x 32 (D)mm
Weight Weight: 93g (Battery, clip included)
Operating Temperature -40℃ ~ +50℃
Operating Humidity 5%~95% RH (Non-condensing)
IP IP 67
Event Log Recent 30 alarms
Alarm Red Flashing LEDs (Light-Emitting Diode), 90dB audible alarm at a distance of 10cm, Vibration alarm
Display Liquid Crystal Display (LCD), Back-light
Battery Manufacture: Vitzrocell / P/N: SB-AA02(P) / System: Lithium Primary Battery Nominal voltage: 3.6V / Nominal capacity: 1.2Ah
Battery Life 24 months, based on 2 minutes of alarm per day
Enclosure Rubber Enclosure
Warranty 2 years

What's in the Box

SENKO SGTP O2 gas detector
Calibration Cap
Manual
Test Report
